Reliance Controls Pro/Tran 2 - 30-Amp (120/240V 4-Circuit) Indoor Transfer Switch w/ Inlet

Image 1
  • Image 1
Price:
$109.11
SKU:
RC-PRO2-30A4I
Brand:
Reliance
Weight:
0.00 LBS
Availability:
Ready Stock
Shipping:
Calculated at checkout
Quantity:
Bookmark and Share

Product Description

Reliance Controls Pro/Tran 2 - 30-Amp (120/240V 4-Circuit) Indoor Transfer Switch w/ Inlet

  • Pro/Tran® 2 Series 30-Amp 4-Circuit 120V Manual Transfer Swtich
  • Same benefits as the original plus new some new features
  • Safest Way to Distribute Power
  • Eliminates dangerous backfeeds and electrical overloads
  • (4) Total Circuits (1" Interchangable Style)
  • Four 15-Amp Single-Pole (120 Volts) circuits
  • Versatile Connection
  • Allows hardwiring OR plug-in connection via power inlet (included)
  • Hinged, Non-Metalic Cover
  • Protects toggle swtiches/breakrs & povides a finished apperance
  • Powder-Coated Steel Cabinet For Indoor Installation
  • 18" Flexible conduit w/ all factory wires clearly marked/colored
  • (6) Combination 1/2" & 3/4" knockouts for easier installation
  • Easily re-configured in the field for multiple 2-pole circuits
  • Safety & Certifications
  • Certified for use by Underwriter Laboratories to UL Stanard 1008
  • Meets all requirements of article 702 of the NEC ANSI/NFPA 70

SPECIFICATIONS

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
3750 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Conduit Length
18
Number of Circuit Breakers
4
Max Generator Input
30 Amps
Maximum Wattage
3750 Watts
UL Listed
Yes
Overview
Weight
15 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
11.25 Inches
Product Width
7.75 Inches
Product Height
4.5 Inches
UPC
815181012595
Transfer Switch Circuits
15A 120V
4
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L14-30R
1
